• High-flow centrifugal pump.
• Pump body of polypropylene reinforced by fiberglass, resistant to pool chemicals to provide excellent durability.
• Turbine of Noryl.
• Stainless steel shaft AISI-316.
• Single-phase 3 HP motors or three-phase 3 HP, 4 HP or 5.5 HP motors, all with IP-55 protection.
• Frequency: 50 Hz (60Hz on demand, add-60 after pump code).
COUNTER CURRENT NOZZLE
• Nozzle made entirely of white ABS and Stainless Steel aretotally unalterable by UV rays and the harsh chemicals generally used in swimming pools.
• Built—in pneumatic pushbutton to operate relay of the pump’s control box.
• Directional jet, venturi outlet, connections.
CONTROL PANEL
• Housed in a clear watertight box with pneumatic electro—pushbutton to ensure complete safety when operating the pump from the water.
• Necessary electrical protection included.
CODE DESCRIPTION
PCC-300-M COUNTER CURRENT PUMP “PCC” 3HP SINGLE PHASE
PCC-300-T COUNTER CURRENT PUMP “PCC” 3HP THREE PHASE
PCC-400-T COUNTER CURRENT PUMP “PCC” 4HP THREE PHASE
PCC-550-T COUNTER CURRENT PUMP “PCC” 5.5HP THREE PHASE
CCN-033 ABS COUNTER CURRENT NOZZLE – CONCRETE /LINER
CCN-033-SS STAINLESS STEEL COUNTER CURRENT NOZZLE – CONCRETE /LINER
CCP-010-M COUNTER CURRENT SYSTEM CONTROL PANEL SINGLE PHASE
CCP-010-T COUNTER CURRENT SYSTEM CONTROL PANEL THREE PHASE
