SOLENOID DRIVEN DOSING PUMPS – HC 897

Context of use:
• Constant flow rate dosing pump with pulse frequency regulation. Easy to set, with a single adjustment potentiometer and a LED. Level probe compatible

Description:
• Analogue electromagnetic constant flow rate dosing pump
• High-strength PBT container, suitable for high temperatures (both places and liquids)
• Level probe input
• Double pulse regulation scale 0-100% or 0-20%
• Power supply: 220VAC – 50/60Hz
• On-Off switch
• IP65 protection
• Analogue interface with one knob and a LED
• Manual priming valve
• Wall or foot mounting (brackets included in the kit)

Technical features:
• DOUBLE REGULATION SCALE 0-100% O 0-20% – precise dosing even at low flow rates
• PVDF BODY PUMP – high chemical compatibility
• FIXING BRACKET – to simplify the installation
• PBT CASE – high mechanical resistance – eco-friendly – ergonomic – low flammability
• BUILT-IN PIPE HOLDER – safe and clean installation
• REMOVABLE CONNECTIONS – easy maintenance of the pump

Standards:
• No. 2004/108/CE EMC directive
• No. 2006/95/CE “DBT low voltage directive”
• No. 2011/65/UE , 2002/96/CE “RoHS and WEEE directives”

Package size: (LxHxW)
192x160x250 mm
