PERISTALTIC DOSING PUMPS – TECHNOPOOL 3

Context of use:
• For private pools with multifunctional built-in tool: pH, Temperature and Rx (upon request).
• Suitable for the dosing of acid/alkaline corrector depending on the pH reading, and for the timed dosing of the disinfectant (like Hydrogen peroxide) depending on water temperature. Also available with the built-in Rx potential reading tool, for a proportional dosing of chlorine.

Description:
•Triple peristaltic pump with built-in timer and pH, Temperature and Redox instruments (T-pH-Rx model only).
• Acid/Alkaline corrector proportional dosing
• Timed dosing of 1-2 disinfectant products whose quantity is compensated depending on the temperature
• Disinfectant dosing proportioned to the Redox potential (T-pH-Rx model only)
• Display with digital controls.
• Acoustic alarms
• Protection password
• Level probes compatible
• Flow sensor
• Connection to the recirculation pump to allow the dosing (V1)
• Measurement range 5-9 pH, 0-999 mV.
• Power supply 220-230V 50/60Hz
• With kit and equipment for a correct installation consists of:
– Suction/injection pipe
– Wall fixing bracket and dowels
– pH, temperature and Rx electrodes (Rx model only)
– Buffer solutions
– Probe holder collars
– Injection valves
– Foot filters.

Standards:
• No. 2004/108/CE EMC directive
• No. 2006/95/CE “DBT low voltage directive”
• No. 2011/65/UE , 2002/96/CE “RoHS and WEEE directives”

Package size: (LxHxW)
390x445x165 mm

Data Sheet   User Manual  Spare part list  Drawing
