PERISTALTIC DOSING PUMPS – SIMPOOL PH

CONTEXT OF USE:
• For private pools up to 200 cu. m for dosing the acid or alkaline corrector with the built-in pH tool.
DESCRIPTION:
• Digital peristaltic pump with built-in pH instrument
• Easy, precise and flexible use.
• Digital display switched on even without circulation flow, flow presence/absence control through a connection to the recirculation pump (Inhibit).
• Level probe compatible.
• The kit includes: pH electrode, 4 m suction/injection pipe, 2 pH buffer solutions to calibrate the electrode, wall fixing bracket and dowels, 2in1 electrode           holder collar and product injection suitable for DN50-63 ADPSTC pipes, foot filter.
• Upon request, the temperature-reading compatible version is available (temperature probe not included).
TECHNICAL FEATURES:
• Power supply: standard 230 VAC – 15 WATT (max)
• Level inputs: standard
• INHIBIT inputs: 230 VAC to activate and allow the dosing (circulation pump)
• Switch: on/off/prime
LIGHT MODEL
• Range 0-14 pH (Adjisutable range alarm)
• Pause mode
PRO MODEL
• Reduced Range 5-9pH (specific for Swimming Pool use)
• Temperature probe connection*
• Range/Maintenance/ OFA/Temperature alarm
• Statistics: Average pH measurement
• Buzzer
STANDARDS:
• No. 2004/108/CE EMC directive
• No. 2006/95/CE “DBT low voltage directive”
• No. 2011/65/UE, 2002/96/CE “RoHS and WEEE
directives”
PACKAGE SIZE: (LXHXW)
250x145x265 mm
