NOZZLES - RETURN WALL INLET

NOZZLES – RETURN WALL INLET

• Injection nozzle designed for high flow rate.
• The innovative design, an inward embrasure form with directional fins improve the distribution of flow and adjustable fins improve the flow distribution.
• The outer-clamping ring nut also has a embrasure and conical form, that allows to distribute extending the flow distribution effect creating a twirled conical effect of the flow right form the very beginning of the water’s emissions 5 socket insert.
• Screw in INOX 316 for mod. Liner, in additional elegant flange cover.
• Flow rate: 13.49m³/h at speed 4m/sec
• In accordance with legislation UNI 13451.
