Description:
FP2 Duplex filter cartridge housings with brass inserts and transparent SAN sump or opaque white sump.
Technical Features:
Head: PP with brass inserts
Sump: Transparent SAN-PP white
O-Ring: NBR 70 Sh A
Max working pressure: 10 BAR Max
Average breaking pressure: 35 BAR Max
PED Hydrostatic test pressure
Max working temperature: 5°C + 50°C min./max
Capacity (empty) at 2 BAR: 3/4”F 108,50 Lt./min. – 1”F 106,60 Lt./min.
Life test: 100,000 cicles from 0-10 BAR
Data Sheet User Manual Accessories
CODE DESCRIPTION
A1120010 DUPLEX FP2 V/T 9″ 3/4 FI 3/4″
A1120020 DUPLEX FP2 V/T 9″ 3/4 FI 1″
A1120110 DUPLEX FP2 V/O 9″ 3/4 FI 3/4″
A1120310 DUPLEX FP2 V/O 20″ FI 3/4″
A1120120 DUPLEX FP2 V/O 9″ 3/4 FI 1″
A1120320 DUPLEX FP2 V/O 20″ FI 1″
