170 TENNIS PRO

DESCRIPTION

The basic synthetic surface in the construction of tenniscourts, with a height of 15mm, made from a twisted yarns polypropylene, available in traditional green and red colors. It is specifically designed for the correct balance between yarn and performance in silica sand, which makes this surface ideal in terms of speed and in the bounce of the ball.

YARN CHARACTERISTICS

Structure………………………………………….Twisted fibrillated
Composition………………………………………………Polyethylene
Dtex………………………….Dtex……………………………………6.6000
Thickness……………Micron………………………………….60
Colour…………………..Red – Green
Yarn weight………..gr/mq…………………………….1.370

TURF CHARACTERISTICS

Pile height…………..mm……………………………………….15
Stitches………………..N/sqm………………………….58.800
N/10 cm………………………..28.00
Filaments…………….N/mq………………………………………..
Total weight……….gr/mq…………………………….2.500
Gauge……………………………………………………………….3/16
Type of production…………………………………….Tufted

RECOMMENDED INFILL
Sand
Size ……………………….mm………………………………0.3-0.9
Quantity……………….kg/m2……………………12 ± 10 %
RUBBER
Size ………………………mm……………………………….0.0-0.0
Quantity……………….kg/m2……………………………0.0-0.0

ROLLS

Length………………….m……………………..Up on request
Width……………………m………………………………..2.0 – 4.0
